BALLUFF BSP00YH BSP B400-EV009-P00S2B-S4 Digital Pressure Sensor

Main Product Information

BALLUFF BSP00YH is a digital pressure sensor with display, identified by the product designation BSP B400-EV009-P00S2B-S4.

The sensor is designed for industrial pressure measurement and automation applications. The BSP00YH provides a measuring range of 0...400 bar and supports IO-Link communication together with configurable analog and switching outputs.

Product Code: BALLUFF BSP00YH

Model: BSP B400-EV009-P00S2B-S4

Product Type: Digital Pressure Sensor with Display

Measuring Range: 0...400 bar

Accuracy: ±0.5 % FSO BFSL

Interface: IO-Link 1.1

Analog Output: 4...20 mA / 0...10 V selectable

Connection: M12x1 male, 4-pin

Process Connection: G 1/4" DIN 3852

BALLUFF BSP00YH Pressure Sensor Features

The BALLUFF BSP00YH belongs to the BALLUFF BSP family of pressure sensors with display and is designed for industrial pressure monitoring and measurement.

• Measuring Range: 0...400 bar

• Accuracy: ±0.5 % FSO BFSL

• Overload Pressure: 650 bar

• Burst Pressure: 1000 bar

• Operating Voltage: 18...30 VDC

• Interface: IO-Link 1.1

• Analog Output: 4...20 mA / 0...10 V selectable

• Switching Output: 2x PNP/NPN, NO/NC selectable

• Connection: M12x1 male, 4-pin

• Process Connection: G 1/4" DIN 3852

• Protection Rating: IP67 when threaded in

Industrial Pressure Measurement

The BALLUFF BSP00YH can be used in industrial systems where pressure measurement, monitoring and control are required.

• Industrial automation

• Hydraulic systems

• Pneumatic systems

• Machine equipment

• Production machinery

• Pressure monitoring

• Industrial process control

• Sensor replacement and maintenance

The actual suitability of the sensor should be checked against the existing equipment requirements, pressure range, process connection, electrical interface and output configuration.

BSP00YH Replacement and Sourcing

When purchasing a replacement for an existing BALLUFF pressure sensor, the complete product code should be checked rather than relying only on the BSP series name.

Main Product: BALLUFF BSP00YH

Complete Model: BSP B400-EV009-P00S2B-S4

The complete designation helps distinguish this sensor from other BSP models with different pressure ranges, electrical configurations or process connections.

For replacement projects, customers should compare the existing product label, pressure range, process connection and electrical configuration before ordering.
